Round Busbar Insulator

Name: Round Busbar Insulator
Brand: BHARTI POWER ENGINEERING
Price: 10.0 INR
Availability: InStock

Price 10.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Round Busbar Insulator Specification

Overheating Protection
YES

IP Rating
IP20

Shape
Round

Operating Temperature
-40C to +120C

Mounting Type
Base Mount

Feature
Excellent Mechanical Strength, Flame Retardant

Connector Type
Threaded Brass Insert

Humidity %
95% RH Max

Insulation Material
DMC Polyester Resin

Surface Finish
Glossy

Product Type
Busbar Insulator

Application
Electrical Panel, Switchgear, Busbar support

Protection Level
High Dielectric Strength

Frequency (MHz)
50-60 Hz

Rated Voltage
1000 V

Color
Red

Dimension (L*W*H)
40 mm x 40 mm x 35 mm

Weight
150 g

Phase
Single Phase

Size
M8 x 40 mm

No Of Poles
1

Connection Type
Threaded Insert (Brass) M8

Material
DMC (Dough Moulding Compound)

Flammability Class
UL 94 V-0

Corrosion Resistance
Excellent

Compression Strength
400 MPa

Installation
Indoor/Outdoor

Torque Strength
Up to 10 Nm

Creepage Distance
25 mm

Round Busbar Insulator Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1000 Pieces Per Week

Delivery Time
3 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About Round Busbar Insulator

Busbar insulator is mainly used for low voltage power distribution cabinets, frequency converters, and other products.By connecting the busbar support copper, it plays a role in fixing, supporting and insulating.

Flame Retardant DMC Material

Crafted from Dough Moulding Compound (DMC) polyester resin, this insulator meets UL 94 V-0 flammability standards, providing reliable fire resistance and operational safety even in demanding environments. Its robust material ensures longevity and consistent performance.

Superior Mechanical and Electrical Protection

Engineered for high compression strength (400 MPa) and torque resistance (up to 10 Nm), this insulator is ideal for securely mounting single-phase busbars. Its high dielectric strength and 25 mm creepage distance contribute to enhanced electrical insulation and operator safety.

Versatile Applications and Mounting

Optimized for both indoor and outdoor installations, this compact insulator (40 mm x 40 mm x 35 mm) features a base mounting system with a threaded brass M8 insert for swift, stable connections in electrical panels, switchgear, and busbar supports.

FAQ's of Round Busbar Insulator:

Q: How does the flame-retardant rating (UL 94 V-0) benefit the safety of this busbar insulator?

A: The UL 94 V-0 rating ensures that the insulator is highly resistant to ignition and will self-extinguish within 10 seconds after being exposed to a flame. This significantly reduces the risk of fire propagation in electrical installations, enhancing operational safety.

Q: What installation environments are suitable for this round busbar insulator?

A: This insulator is designed for both indoor and outdoor applications, owing to its excellent corrosion resistance, wide operating temperature range (-40C to +120C), and IP20 rating. It performs reliably in various humidity conditions up to 95% RH.

Q: When should this insulator be used in electrical systems?

A: It is most suitable for applications requiring high mechanical strength and dielectric insulation, such as supporting busbars in electrical panels, switchgear, or areas where high temperature and flame resistance are critical factors.

Q: Where is the best location to mount this busbar insulator?

A: The insulator is optimized for base mounting in electrical enclosures, panels, or switchgear assemblies, and should be secured using the brass M8 threaded insert for stable and safe installation.

Q: What is the step-by-step process for installing the insulator?

A: To install, position the insulator on the designated mounting base, align the brass threaded insert with the mounting hole, and fasten securely using an M8 x 40 mm bolt or stud to achieve up to 10 Nm of torque, ensuring firm and reliable contact with the busbar.

Q: How does the product's creepage distance and dielectric strength ensure operational reliability?

A: A creepage distance of 25 mm and high dielectric strength minimize the risk of electrical leakage or flashover, providing secure phase isolation and reducing the chance of short circuits, thus ensuring consistent electrical performance.

Q: What are the key benefits of using this round busbar insulator over conventional options?

A: This insulator delivers superior flame retardancy, exceptional mechanical strength, resistance to corrosion and extreme temperatures, quick and secure threaded mounting, and high protection levels, making it a dependable choice for modern electrical infrastructure.
